FEATURES
SPECIFICATIONS
| GENERAL FEATURE | |
| Section | Specifications |
| Display type | LED Backlight, Wide TFT LCD |
| Viewable Size | 26 inch diagonal |
| Resolution | 1920 x 1200 @60Hz |
| Aspect Ratio | 16:10 |
| Brightness | 350cd/㎡ |
| Contrast Ratio | 1500:01:00 |
| Response Time | 20ms |
| Active Area | 550.08 (H) x 343.8 (V) mm |
| Pixel Pitch | 0.2865 (H) x 0.2865 (V) mm |
| Viewable Angle | 176° RL / 176° UD |
| Support Color | 16.7M colors |
| Synchronization Range | 31~80 Hz (Horizontal) |
| 55~76 Hz (Vertical) | |
| Detectable Resolution | 640 x 480, 800 x 600, |
| 1024 x 768, 1280 x 1024 | |
| 1920 x 1200 | |
| Connector Types | 1 x HDMI (Standard) |
| 1 x DVI (DVI 24p female) | |
| 1 x RGB (D-SUB 15p female) | |
| Power Specification | 100~230VAC 50/60Hz (IEC Standard Type) or DC24V (Terminal Block) |
| Power Consumption | 45W (MAX) |
| Product Dimension | 621 (W) x 80 (D) x 435 (H) mm |
| Weight | 13kg |
| Temperature Range | Operating : -15℃ to +55℃ |
| Non-Operating : -20℃ to +60℃ | |
| Humidity Range | Operating : up to 95% |
| Non-Operating : up to 95% | |
| Options | Projected Capacitive Touch Screen |
| Anti Glare Glass | |
| RS-232/422/485 | |
| Composite Video | |
| Buzzer | |
| IP-Rating | IP65 Front |
| Test Approval | IEC 60945 4th, IACS E-10, IEC 60529 |
| Certification | DNV |
